Large Hdpe Pipe Manufacturer

Large Diameter HDPE Pipe Supplier

900mm Hdpe Pipe, 1000mm Hdpe Pipe, 1200mm Hdpe Pipe, 1400mm Hdpe Pipe, 1600mm Hdpe Pipe, 1800mm Hdpe Pipe, 2000mm Hdpe Pipe, 2200mm Hdpe Pipe, 2500mm Hdpe Pipe

Large Diameter Hdpe Pipe

Specification & Dimension

	Nominal Wall Thickness (mm)
Standard Dimension Ratio	SDR11	SDR13.6	SDR17	SDR21	SDR26	SDR33	SDR 41
Nominal Pressure	1.6MPa (PN16)	1.25MPa (PN12.5)	1.0MPa (PN10)	0.8MPa (PN8)	0.6MPa (PN6)	0.5MPa (PN5)	0.4MPa (PN4)
Nominal External Diameter
1000	90.9	72.5	59.3	47.7	38.2	30.6	24.5
1200	109.1	88.2	67.9	57.2	45.9	36.7	29.4
1400		102.9	82.4	66.7	53.5	42.9	34.3
1600		117.6	94.1	76.2	61.2	49.0	39.2
1800			105.9	85.7	69.1	54.5	43.8
2000			117.6	95.2	76.9	60.6	48.8
2250				107.2	86.0	70.0	55.0
2500				119.1	95.6	77.7	61.2
2500-3000	OEM

Large Diameter HDPE Pipe Feature

1. Large diameter HDPE pipes offer impact resistance and durability for high pressure applications.
2. PE 100 pipe has excellent wear resistance and scratch resistance, and can keep the surface intact even under harsh conditions.
3. Large Diameter HDPE pipes have strong impact resistance, effectively resist external physical damage and extend service life.
4. DN1000-DN3000 HDPE pipes are smooth, have low friction resistance, are easy to install and maintain.
5. Large diameter HDPE pipes are made from non-toxic and recyclable materials with a lower carbon footprint.

Large Diameter HDPE Pipe Application

1. Large diameter HDPE pipes can be used in municipal and rural water supply networks, as well as long-distance water transmission.
2. Large diameter HDPE pipe can be used in gravity and pressure sewer systems, industrial and municipal sewage pipes.
3. Large diameter PE pipe are suitable for large irrigation networks, distribution systems on farms and plantations, and farmland drainage systems.
4. HDPE pipe can be used in dewatering systems, acidic or abrasive fluid handling in open pit and underground mining.
5. Large Diameter PE pipes can be used in oil and gas industry.
6. DN1000-DN3000 HDPE pipe can be used as underwater pipes across streams or lakes, and dredging floating pipes.
